| Name: | Columnar zeolite manufacturing |
|---|---|
Product Description
The columnar zeolite is balanced with a variety of molecular sieve adsorption components, using the extrusion preparation process, so that the effective components are evenly dispersed in the columnar zeolite, the addition of porous materials effectively expand the contact area of organic gas and VOCs gas, and improve the adsorption effect of columnar zeolite.
Specifications sheet
Columnar zeolite specification performance parameter table |
|||
Specifications |
Parameters |
||
|
Exterior color |
Light yellow or white |
|
Diameter |
Phi is 4 mm |
||
long |
5- 10mm |
||
Specific gravity |
M1 |
500±50Kg/m³ |
|
M0 |
600±50Kg/m³ |
||
Performance parameters |
Design adsorption temperature |
30 °C |
|
Maximum adsorption temperature allowed |
50 °C |
||
Minimum adsorption temperature allowed |
No limits |
||
Desorption temperature |
150-500 °C |
||
Humidity for design use |
65% |
||
Maximum humidity allowed for use |
80% |
||
Minimum allowable use humidity |
No limits |
||
Columnar zeolite wind resistance |
< 0.1 Kpa/ layer |
||
Compressive strength |
1.5 MPa |
||
