Name: | Porous zeolite for VOCs |
---|---|
Product Description
The pore size of zeolite is uniform, the internal void structure is developed, the specific surface area is large, the adsorption ability is strong, containing a large number of invisible pores, porous zeolite zeolite micropores effectively adsorb VOCs gas,
when VOCs gas through porous zeolite zeolite zeolite, dense micropores can effectively adsorb VOCs gas molecules, Molecular gravity on the solid surface produced a "surface force", when the VOCs gas flow, some organic gas molecules in the gas due to do irregular movement and collision to the surface of the adsorbent, the surface produces molecular concentration, so that the number of organic molecules in the VOCs gas to reduce, to achieve the purpose of adsorption.
Specifications sheet
Porous zeolite zeolite specification performance parameter table |
||
Specifications |
Parameters |
|
Specification parameters |
Exterior color |
White or pale yellow |
Shape |
spherical |
|
Particle size |
1-2mm |
|
Packing density |
780±20Kg/m³ |
|
Macroscopic surface area |
2880 m²/m³ |
|
Performance parameters |
Design adsorption temperature |
30 ° C |
Maximum adsorption temperature allowed |
50 ° C |
|
Minimum adsorption temperature allowed |
No limits |
|
Desorption temperature |
150-500 ° C |
|
Design service humidity |
65% |
|
Maximum humidity allowed for use |
80% |
|
Minimum allowable use humidity |
No limits |
|
Porous zeolite zeolite wind block |
< 0. 15kpa/ layer |
|
Zeolite model |
adsorption capacity |
Recommended concentration |
Porous zeolite |
20-100Kg/m³ |
>1000mg |
